10Micron GM2000HPS II Combi Portable Equatorial Mount

About This Product

This 13.2 lbs. (6 kg) counterweight is exclusively designed for GM/AZ2000 mounts. A precise 40mm hole offers a smooth movement on the shaft, and facilitates the balancing operations and the stainless steel guarantees no corrosion. The ergonomic screw will ensure a safe tightening.

About This Product

This 26.4 lbs. (12 kg) counterweight is exclusively designed for GM/AZ2000 mounts. A precise 40mm hole offers smooth movement on the shaft, and facilitates balancing operations and the stainless steel guarantees no corrosion. The ergonomic screw will ensure a safe tightening.

About This Product

The Losmandy dovetail clamping plate 3” allow the use of standard Losmandy slide bar mounted optical tubes; this product is all CNC machined, black anodized aluminum. Two locking knobs ensure “top of safety” for your instruments. Lenght: 200mm.

About This Product

The Losmandy dovetail clamping plate 3″ XL offers a length of 350mm (13.8”) and three security locking knobs, in order to offer a very high level of stability and safety, especially for heavier and longer optical configurations.

About This Product

The “Maxi”-dovetail clamping plate 4″ is designed to accept 4” 10Micron dovetail slide bars, suitable for heavier configurations. Advisable for example for optical tubes larger than 14” or for dual telescope setup. Lenght 200mm; 2 security locking knobs. Note for GM3000 & GM4000 users: Although it should be possible to accommodate this plate directly on the top of the GM3000 & GM4000 mount, due to the low profile of the clamping plates we strongly recommend using the special Flange Adapters 10M3545/10M4545 in order to operate the plate’s knobs with enough clearance.

About This Product

The “Maxi”-dovetail clamping plate 4″ XL is designed to accept 4” 10Micron dovetail slide bars, suitable for heavier configurations. Advisable for example for optical tubes larger than 14” or for dual telescope setup. Lenght 350mm; 3 security locking knobs. Note for GM3000 & GM4000 users: Although it should be possible to accommodate this plate directly on the top of the GM3000 & GM4000 mount, due to the low profile of the clamping plates we strongly recommend using the special Flange Adapters 10M3545/10M4545 in order to operate the plate’s knobs with enough clearance.

About This Product

This special double plate is designed to allow a parallel mounting of two optical tubes on the 10Micron mounts. The bottom slide is a standard 3” dovetail bar (Losmandy compatible) #10M2130; the clamping plates are two 3” Losmandy compatible (#10M2085). All the components are CNC machined, black anodized aluminum. There are 3 different possible distances between the two clamps: approx. 210, 245 and 281mm (8.3”, 9.6”, 11”). Note: – The GM1000 HPS Mount needs the #10M1105 Adapter in order to mantain the corret encoder’s position references – All the other mounts require a #10M2085 or #10M2185 3″ Losmandy clamping plate.

About This Product

This special double plate is designed to allow a parallel mounting of two optical tubes on the 10Micron mounts. The bottom slide is a 4” dovetail bar 400mm long with special threaded holes (#10M2199); the clamping plates are 3” Losmandy compatible and 200mm long (#10M2085). All the components are CNC machined, black anodized aluminum. There are 3 different possible distances between the two clamps: appr. 210, 245 and 281mm (8.3”, 9.6”, 11”). Included in the set is a Maxi clamping plate (#10M2135) which fits directly on the GM2000 mounts and via the following adapters on the GM3000 and GM4000 mounts: #10M3545 | Flange adapter for clamping plates (GM3000) #10M4545 | Flange adapter for clamping plates (GM4000)

About This Product

This special cover, made of Cordura, ensures a good protection for your GM2000 mount; very easy to lace and remove thanks to a zip system, which also allows to place the cover with installed payload on the mount.

About This Product

These cases are made of a special resin compound which offers a combination of high elasticity, increased shock absorption, reduced transport weight, and resistance against temperature extremes. They also ensure a perfect barrier against dust, humidity, sand, etc. The Internal padding is cut to accommodate the instruments. Three cases, with a trolley configuration, contain the GM2000 Ultraport mount; the other one contains the counterweights and shaft, the electronic parts (control box + hand controls and cables), and other small accessories.

About This Product

This Pier flange adapter is made of electroplated steel and it’s designed in order to accommodate the GM2000 mount on a flat-topped metal pier. It fits the Base adapter flange of the GM2000 (#10M2095), normally supplied with the Mount.

About This Product

This optional base adapter flange kit is designed to accommodate the GM2000 mount on the Pier Adapter flange (#10M2090), to the Centaurus II tripod, or directly on a fixed pier. It’s made of a fine black anodized aluminum and includes all the necessary knobs, screws and the azimuth pin. It’s usually provided with the GM2000 Mount.

About This Product

This Switching Power Supply is a very high quality and reliable device; it accepts 110 to 240V AC input; the output ensures the proper 24V, 6.67A (160W) power supply to the v.2 GM2000HPS, GM3000HPS, GM4000HPS mounts.

About This Product

This Power Supply is a very high quality and reliable 12V to 24V DC converter. It ensures that, from a 12V DC power source, the proper 24V, 5A (120W) output power is supplied to the GM1000 and GM2000 mounts. The input power cable is provided with a standard car lighter plug. It is perfect for “field” observations using a suitable 12V battery (not supplied).

About This Product

This cardboard box, fitted with Special shaped Foam, will ensure a safe shipping & transport and an eventual warranty repair return. Provided with a suitable handle. It’s usually included in the mount’s standard pack; designed only for GM2000 and GM2000 HPS mounts.

About This Product

This accessory allows to accommodate the 10Micron electronic control box on round metal pier. Made of fine machined black anodized aluminum.

About This Product

The GM2000 and AZ2000 mounts are available in a special version for very low temperature operations. This option allows the Mount to operate until -30°C (-22° F) and features the following special modifications: - Special low-temperature lubricants certified until -60°C or lower - Special copper wiring, silicone sheathed - Electronic components certified for temperatures down to -40°C - Endurance tested at low temperatures in our laboratory All 10Micron mounts feature special systems in their mechanics in order to compensate thermal variations. This option is intended for brand new mounts to be ordered; contact us for already delivered mounts.
