10Micron GM 4000 HPS II Equatorial Mount

About This Product

The Losmandy dovetail clamping plate 3” allow the use of standard Losmandy slide bar mounted optical tubes; this product is all CNC machined, black anodized aluminum. Two locking knobs ensure “top of safety” for your instruments. Lenght: 200mm.

About This Product

The “Maxi”-dovetail clamping plate 4″ XL is designed to accept 4” 10Micron dovetail slide bars, suitable for heavier configurations. Advisable for example for optical tubes larger than 14” or for dual telescope setup. Lenght 350mm; 3 security locking knobs. Note for GM3000 & GM4000 users: Although it should be possible to accommodate this plate directly on the top of the GM3000 & GM4000 mount, due to the low profile of the clamping plates we strongly recommend using the special Flange Adapters 10M3545/10M4545 in order to operate the plate’s knobs with enough clearance.

About This Product

This special double plate is designed to allow a parallel mounting of two optical tubes on the 10Micron mounts. The bottom slide is a standard 3” dovetail bar (Losmandy compatible) #10M2130; the clamping plates are two 3” Losmandy compatible (#10M2085). All the components are CNC machined, black anodized aluminum. There are 3 different possible distances between the two clamps: approx. 210, 245 and 281mm (8.3”, 9.6”, 11”). Note: – The GM1000 HPS Mount needs the #10M1105 Adapter in order to mantain the corret encoder’s position references – All the other mounts require a #10M2085 or #10M2185 3″ Losmandy clamping plate.

About This Product

The “Maxi”-dovetail clamping plate 4″ is designed to accept 4” 10Micron dovetail slide bars, suitable for heavier configurations. Advisable for example for optical tubes larger than 14” or for dual telescope setup. Lenght 200mm; 2 security locking knobs. Note for GM3000 & GM4000 users: Although it should be possible to accommodate this plate directly on the top of the GM3000 & GM4000 mount, due to the low profile of the clamping plates we strongly recommend using the special Flange Adapters 10M3545/10M4545 in order to operate the plate’s knobs with enough clearance.

About This Product

This special double plate is designed to allow a parallel mounting of two optical tubes on the 10Micron mounts. The bottom slide is a 4” dovetail bar 400mm long with special threaded holes (#10M2199); the clamping plates are 3” Losmandy compatible and 200mm long (#10M2085). All the components are CNC machined, black anodized aluminum. There are 3 different possible distances between the two clamps: appr. 210, 245 and 281mm (8.3”, 9.6”, 11”). Included in the set is a Maxi clamping plate (#10M2135) which fits directly on the GM2000 mounts and via the following adapters on the GM3000 and GM4000 mounts: #10M3545 | Flange adapter for clamping plates (GM3000) #10M4545 | Flange adapter for clamping plates (GM4000)

About This Product

This special double plate is designed to allow a parallel mounting of two optical tubes on the 10Micron mounts. The bottom slide is a 4” dovetail bar 400mm long with special threaded holes (#10M2199); the clamping plates are 3” Losmandy compatible and 350mm long (#10M2185). All the components are CNC machined, black anodized aluminum. There are 3 different possible distances between the two clamps: appr. 210, 245 and 281mm (8.3”, 9.6”, 11”). Included in the set is a Maxi clamping plate (#10M2135) which fits directly on the GM2000 mounts and via the following adapters on the GM3000 and GM4000 mounts: #10M3545 | Flange adapter for clamping plates (GM3000) #10M4545 | Flange adapter for clamping plates (GM4000)

About This Product

The 10Micron 5" Dovetail Clamping Plate is purpose-built for heavy optical configurations on GM3000 and GM4000 mounts — offering a wider, more stable grip than standard 3" or 4" clamping plates.

About This Product

The Giant Dovetail clamping plate 8” is an extra sturdy, black aluminum anodized machined clamp suitable for 8″ dovetail bars including those for Planewave OTA’s CDK 17, CDK 20 and CDK 24. Although it fits the medium-size the 2000HPS mounts, this clamping plate is specially recommended for very heavy optical configurations on the GM3000 and GM4000 mounts.

About This Product

This Pier flange adapter is made of electroplated steel and it’s designed to accommodate the GM/AZ4000 mounts on top of a flat-topped pier. One of these is supplied with the mandatory shipping kit (#10M4199).

About This Product

300 mm length dovetail bar, Losmandy style (3”), made of black an3odized aluminum; it can be used directly on the GM1000 Mount.

About This Product

400 mm length dovetail bar, Losmandy style (3”), made of black anodized aluminum; it can be used directly on the GM1000 mount or on the other mounts with suitable adapters.

About This Product

500 mm length dovetail bar, Losmandy style (3”), made of black anodized aluminum; it can be used directly on the GM1000 mount or on the other mounts with a suitable adapter.

About This Product

400mm length dovetail bar, 10Micron 4” style, made of black anodized aluminum, compatible with the #10M2135 “Maxi”-dovetail clamping plate 4″. This configuration is suitable for heavier configurations. Advisable for example for optical tubes larger than 14” or for dual telescope setup.

About This Product

500mm length dovetail bar, 10Micron 4” style, made of black anodized aluminum, compatible with the #10M2135 “Maxi”-dovetail clamping plate 4″. This configuration is suitable for heavier configurations. Advisable for example for optical tubes larger than 14” or for dual telescope setup.

About This Product

This Switching Power Supply is a very high quality and reliable device; it accepts 110 to 240V AC input; the output ensures the proper 24V, 6.67A (160W) power supply to the v.2 GM2000HPS, GM3000HPS, GM4000HPS mounts.

About This Product

This accessory allows to accommodate the 10Micron electronic control box on round metal pier. Made of fine machined black anodized aluminum.

About This Product

The GM4000 mandatory shipping kit (also suitable for the AZ4000 HPS) is composed of the GM4000 105 x 85 x 65 cm shipping wooden pallet-box (#10M4100)and the pier adapter (#10M4090). Both are necessary items when the mount will be shipped. Shipping charges will be calculated individually for each destination and will be billed separately. The included pier adapter (#10M4090) will be needed later when mounting the GM 4000 onto a pier. This strong plate of solid steel is mandatory not only to secure the mount on the pallet during transport but also later to translate the full loading capacity of the Mount onto the pier.

About This Product

Shipping wooden pallet-box for the GM/AZ4000 mounts, for safe shipping and for warranty repair return (NOT included in the mount’s standard pack ). It is included in the GM/AZ4000 mandatory shipment kit (#10M4199).

About This Product

The GM3000 and AZ3000 mounts are available in a special version for very low temperature operations. This option allows the Mount to operate until -30°C (-22° F) and features the following special modifications: - Special low-temperature lubricants certified until -60°C or lower - Special copper wiring, silicone sheathed - Electronic components certified for temperatures down to -40°C - Endurance tested at low temperatures in our laboratory All 10Micron mounts feature special systems in their mechanics in order to compensate thermal variations. This option is intended for brand new mounts to be ordered; contact us for already delivered mounts.
